PAGE 2-3
CHAPTER 1 GENERAL INFORMATION AND OPERATING INSTRUCTIONS
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
2 OPERATION
JANUARY 10, 2017
INSTRUMENTS AND CONTROLS
Item Description Position
or Note
Function
1 Running Lights On
Lights ON
O
Lights OFF
2 Retract Stabilizers
Indiator
Red
Light ON indicates stabilizers are down
3 Remote Switch O
Indicator
Red
Light ON indicates remote switch on platform is in
the OFF position and lift will not start.
4 Brake Fault
Indicator
Red
Light ON indicates a fault with the braking system
5 High Engine
Temperature
Red
Light ON indicates excessive engine temperature
6 Low Engine Oil
Pressure Light
Red
Light ON indiates engine oil pressure is too low for
safe engine operation
7 Low Volts Light Red
Light ON indicates no battery charging
8 Panel Light
Illuminates panel when headlight are ON
9 Stabilizer Switch UP
Raises stabilizers
Down
Lowers stabilizers
10 Operational Safety
Switch
UP
Hold either up or down in conjuntion with platform
and stabilizer switches.
DOWN
11 Platform Switch UP
Raise Platform
Down
Lower Platform
12 Park Brake ON
Indicator
Red
Paking brake in engaged
13 Hour meter or
CAN Gauge (E A)
Records engine operating hours
Indicates engine problem (see chapter 5)
14 Fuel Gauge
Indicates quantity of fuel in tank
15 Not Used
16 Emergency Pump
Switch
ON
Provides electrical and hydraulic power to platform
and stabilizer circuits if main engine power is
disabled
OFF
No aect on any circuits
17 Engine Ignition
Switch
OFF
Ignition OFF
RUN
Ignition ON
START
Crank engine
18 Glow Plug Indicator
ON indicates glow plugs are heating
19 Fuse Panel
Circuit fuses
Property of American Airlines
