PAGE 2-4
CHAPTER 1 GENERAL INFORMATION AND OPERATING INSTRUCTIONS
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
2 OPERATION
JANUARY 10, 2017
INSTRUMENTS AND CONTROLS
Item Description Position
or Note
Function
20
Platform Engine
Ignition Switch
OFF
Ignition OFF
RUN
Ignition ON
START
Crank engine
21 Remote Emergency
Pump Switch
Starts emergency pump for hydraulic system if main
pump fails
22 Remote Operator
Safety Switch
UP Allows use of platform and stabilizer hydraulics
DOWN
23 Remote Platform
Up/Down switch
UP Raises platform
DOWN Lowers platform
24 Remote Stabilizers
Up/Down Switch
UP Raise stabilizers
DOWN Lower stabilizers
27 Horn Button Press Sounds Horn
28 Transmission
Selector
PUSH
Forward
Vehicle will move in reverse
CENTER Neutral
PULL
Back
Vehicle will move forward
29 Park Brake
Lever
PULL UP Applies parking brake
PUSH
DOWN
Releases parking brake
30 Throttle Pedal PRESS Increases speed
31 Brake Pedal PUSH Slows vehicle
32 Hour Meter Records engine operating hours
33 Transmission Problem ON Transmission problem (E. A)
34 Turn Signal Standard automotive style (E A)
Property of American Airlines
