NMC-WOLLARD TMPS-200 - Page 129

CHAPTER 4 REPAIR PARTS MARCH 31, 2007
4 ILLUSTRATED PARTS LIST PAGE 11
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
3- 12708W Main Stair Assembly, 2 of 2 “D” Size Ref
13 12703W Support, LWR Step 1
22 17676 Angle, Tread 24
23 17677 Angle, Riser 28
26 12769W Pin, 1.50 x 8.75, ETD-150 4
27 308647 HHCS, Drilled, 7/16-20 x .84" 8
28 12708.28 Top Cap, Main Stair, x 200" 2
30 12524 Spacer, Skin 18
36 12776 Latch Assy., Safety 1
37 Comm Screw, Pan HD Mach, #10-32NF x
2.00"
40
38 Comm Nut, Lock, #10-32NF 40
39 Comm HHCS, 1/4-28NF x 1.25" 20
43 12712W Support, Cylinder 1
44 12748W Support Pad, Cylinder 1
45 Comm HHCS, 3/8-16 x 2.00 4
46 Comm Nut, Lock, 3/8-16 4
51 12751W Solenoid Installation (See Figure 16) 1
52 Comm HHCS, 7/16-14 x 2" 6
53 Comm Nut, Lock, 7/16-14 6
60 3.1453 Washer, Bevel 4
63 12715 Flip Step Structure 1
64 3.3219 Bolt, Shoulder, 0.50 x 2.25 Lg. x
3/8-16 Thd
2
65 Comm Nut, Jam Lock, 3/8-16 2
66 Comm Washer, ½", USS 6
68 Comm Washer, 3/8" 2
NS Comm Rivet, Pop, 3/8" 2
NS 3.3241 2771-0617 Monobolt, 3/16" Dia (V19738) A/R
NS 19448 Skin, Main Section, Inner, Lwr LH &
RH
2
NS 19447 Skin, Main Section, Inner, Upr LH &
RH
2
