PARTS LIST
LISTA DE PIEZAS
23
Frontier Carpet Extractor (06–01)
RECOVERY TANK GROUP
CONJ. DESPOSITO RECUPERAR
REF PART # DESCRIPTION QTY.
∇ 100103 ASSEMBLY, LID 1
 1 600812 LID, OUTER RING ONLY (BLACK) 1
 2 100105 LID, CENTER ONLY (CLEAR) 1
3 140900 SCREW, 10–24 X 3/4 6
4 602715 BLADDER, 10 GAL. MODEL 1
5 578729 DECAL, READ MANUAL 1
6 602448 STANDPIPE, 10 GAL. MODEL 1
7 180613 FLOAT, SHUT–OFF 1
8 606088 NIPPLE 1
9 230159 O–RING, STANDPIPE 1
10 210240 NUT, FLANGED METAL 1
∇ 11 701005 ASM., DOME 1
 12 240217 KNOB, DOME 2
 13 140037 WASHER, NYLON 2
 14 100042 GASKET, RECOVERY DOME 1
 15 120399 DECAL, DO NOT ALLOW FOAM 1
∇ 701061 ASM., DRAIN HOSE 1
 16 230831 KNOB, DRAIN HOSE 1
 17 230882 STRAP 1
 18 140056 WASHER, FENDER 1
 19 140955 PLUG 1
20 140921 SLEEVE, DRAIN HOSE 1
21 140072 CLAMP 2
22 160416 HOSE, DRAIN 1
∇ ASSEMBLY / CONJUNTO
 INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
 RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS PARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
23 140307 CLAMP 1
24 230696.BK BRACKET, DRAIN HOSE 1
25 140825 SCREW, #6X3/4 2
26 230843 BRACKET, TANK BRACE
W/THREADS
1
27 230844 BRACKET, TANK BRACE W/HOLES 1
28 140259 SCREW, 1/4–20X5/8 1
29 230955 CLAMP 1
30 140553 SCREW, 1/4–20X1/2 1
31 140016 WASHER, LOCK 2
32 140000 WASHER, 1/4 FLAT 8
33 102569 TANK, GASKET 2
34 140227 STUD, 1/4–20X5 3
35 608472 DECAL, FRONTIER 2
36 608186 DECAL, “NOBLES” 1
37 608532 TANK, RECOVERY, GREEN 1
38 630420 DECAL, FLAMMABLE MATERIAL 1
39 603547 HOSE, VAC 1–1/2 X 46” W/CUFFS 1
40 120906 DECAL, IMPORTANT DRAIN 1
41 120907 DECAL, IMPORTANT ALWAYS
CLOSE
1
42 140637 NUT, WELL 10–32 2
43 140887 SCREW, 1024X3/8 PANPHL 2
44 230755.BK BRACKET, CORD HANGER BLACK 1
