PARTS LIST
LISTA DE PIEZAS
27
Frontier Carpet Extractor (06–01)
CHASSIS GROUP
CONJUNTO TELAIO
REF PART # DESCRIPTION QTY.
1 100118 GASKET, VAC MOTOR (120V) 1
100038 GASKET, VAC MOTOR
(230V/240V)
1
2 130996 MOTOR, VAC (120V) 1
603042 COVER, VAC FAN (120V) 1
3 140501 NUT 1/4–20 NYLOCK 4
4 600177 BRUSH, CARBON 2/PK (120V) 2
190158 BRUSH, CARBON 2/PK
(230V/240V)
2
5 140308 CLAMP, HOSE 1–5/16 TO 2–1/4 2
6 606160 HOSE, EXHAUST 2” X 24” 1
7 230390 HINGE, TANK 1
8 140885 SCREW, 1/4–20X1/2 TRSPHL 7
9 230739 AXLE 1
10 140008 WASHER, 1/2 FLAT 2
11 103068 WHEEL, 10” X 1.75” 2
12 103019 CAP, HUB 2
13 230746 BRACKET, AXLE OFFSET 2
14 140016 WASHER, 1/4 LOCK 4
15 140259 SCREW, 1/4–20X5/8 HXHDCP 4
 RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS PARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
16 140804 SCREW, 10–24X1 1
17 140000 WASHER, 1/4 FLAT 6
18 140501 NUT, 1/4–20 NYLOCK 3
19 140208 SCREW, 1/4–20X1 3
20 604640 BRACKET, CHASSIS SUPPORT 1
21 140899 SCREW, 10–24X1–1/4 4
22 140011 WASHER, 3/16 FLAT 8
23 140226 SCREW, 5/16–18X3/4 HXHDCP 4
24 140015 WASHER, 5/16 SPLITLOCK 4
25 103065 CASTER, SWIVEL 4” 1
26 140256 SCREW, 3/8–16XX2–1/2 2
27 140028 WASHER, FLAT 2
28 608831 CHASSIS, GREEN 1
29 140519 NUT, 10–24 KEP 8
30 140012 WASHER, 3/16 FLAT 4
31 180103 PUMP, 100PSI (120V) 1
32 140519 NUT, 10–24 KEP 3
33 N/A DECAL, CE (240V MODEL) 1
34 N/A DECAL, KEMA (240V MODEL) 1
35 N/A DECAL, EMC APPROVED
(240V MODEL)
1
