Nokia E52 User Manual

Remove the memory card
Important: Do not remove the memory card during an operation when the card
is being accessed. Doing so may damage the memory card and the device, and corrupt
data stored on the card.
1 Press the power key briefly, and select Remove memory card.
2 To prevent the battery from coming loose, place the device so that the back cover
is facing up.
3 Remove the back cover.
4 Press the end of the memory card to release it from the memory card slot, and
remove the card.
5 Replace the back cover.
Keys and parts
Keys and parts
1 Power key
2 Light sensor
3 Selection key. Press the selection key to perform the function displayed above it.
4 Home key
5 Call key
6 Calendar key
7 Microphone
8 E-mail key
9 End key
10 Backspace key. Press the key to delete items.
11 Selection key
14 Get started

Nokia E52 Specifications

General

Technology	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 900 / 2100
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
Dimensions	116 x 49 x 9.9 mm, 54 cc (4.57 x 1.93 x 0.39 in)
Weight	98 g (3.46 oz)
SIM	Mini-SIM
Display Type	TFT, 16M colors
Display Resolution	240 x 320 pixels, 4:3 ratio (~167 ppi density)
OS	Symbian OS 9.3, Series 60 v3.2 UI
Internal Memory	60MB
Alert types	Vibration; Downloadable polyphonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
GPS	Yes, with A-GPS; Nokia Maps
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Talk time	Up to 8 h (2G) / Up to 6 h (3G)
Announced	2009, May
Display Size	2.4 inches
CPU	ARM 11
Card slot	microSDHC (dedicated slot)
Camera Single	3.2 MP
WLAN	Wi-Fi 802.11 b/g
Sensors	Accelerometer
Battery	Removable Li-Po 1500 mAh (BP-4L)
Stand-by	Up to 672 h (2G) / Up to 432 h (3G)
Colors	Metal Grey
SAR	0.79 W/kg (body)
