Nokia E52 User Manual

Incoming calls when roaming — Prevent incoming calls when outside your home
country.
International calls except to home country — Prevent calls to foreign countries or
regions, but allow calls to your home country.
To check the status of voice call barrings, select the barring option and Options > Check
status.
To deactivate all voice call barrings, select a barring option and Options > Deactivate
all barrings.
To change the password used for barring voice and fax calls, select Options > Edit
barring password. Enter the current code, then the new code twice. The barring
password must be four digits long. For details, contact your service provider.
Bar net calls
Select Menu > Ctrl. panel > Settings and Phone > Call barring > Internet call
barring.
To reject net calls from anonymous callers, select Anonymous call barring > On.
Send DTMF tones
You can send dual-tone multifrequency (DTMF) tones during an active call to control
your voice mailbox or other automated phone services.
Send a DTMF tone sequence
1 Make a call, and wait until the recipient answers.
2 Select Options > Send DTMF.
3 Enter the DTMF tone sequence, or select a predefined sequence.
Attach a DTMF tone sequence to a contact card
1 Select Menu > Contacts. Select a contact and Options > Edit > Options > Add
detail > DTMF.
2 Enter the tone sequence. To insert a pause of about 2 seconds before or between
DTMF tones, enter p. To set the device to send the DTMF tones only after you select
Send DTMF during a call, enter w. To enter p and w with the keypad, press *
repeatedly.
3 Select Done.
Talking theme
Select Menu > Ctrl. panel > Themes and Standby > Talking theme.
Phone 71

Nokia E52 Specifications

General

Technology	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 900 / 2100
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
Dimensions	116 x 49 x 9.9 mm, 54 cc (4.57 x 1.93 x 0.39 in)
Weight	98 g (3.46 oz)
SIM	Mini-SIM
Display Type	TFT, 16M colors
Display Resolution	240 x 320 pixels, 4:3 ratio (~167 ppi density)
OS	Symbian OS 9.3, Series 60 v3.2 UI
Internal Memory	60MB
Alert types	Vibration; Downloadable polyphonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
GPS	Yes, with A-GPS; Nokia Maps
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Talk time	Up to 8 h (2G) / Up to 6 h (3G)
Announced	2009, May
Display Size	2.4 inches
CPU	ARM 11
Card slot	microSDHC (dedicated slot)
Camera Single	3.2 MP
WLAN	Wi-Fi 802.11 b/g
Sensors	Accelerometer
Battery	Removable Li-Po 1500 mAh (BP-4L)
Stand-by	Up to 672 h (2G) / Up to 432 h (3G)
Colors	Metal Grey
SAR	0.79 W/kg (body)
