Nokia E52 User Manual

Features that use WLAN, or that are allowed to run in the background while using other
features, increase the demand on battery power and reduce the battery life.
Your device supports the following WLAN features:
• IEEE 802.11b/g standard
• Operation at 2.4 GHz
• Wired equivalent privacy (WEP), Wi-Fi protected access (WPA/WPA2), and 802.1x
authentication methods. These functions can be used only if they are supported by
the network.
Important: Always enable one of the available encryption methods to increase
the security of your wireless LAN connection. Using encryption reduces the risk of
unauthorised access to your data.
When the device is in the offline profile, you can still use WLAN, if available. Remember
to comply with any applicable safety requirements when establishing and using a WLAN
connection.
Tip: To check the unique media access control (MAC) address that identifies your device,
enter *#62209526# in the home screen.
Note: Using WLAN may be restricted in some countries. For example, in France,
you are only allowed to use WLAN indoors. For more information, contact your local
authorities.
See WLAN availability
To set your device to show wireless LAN (WLAN) availability, select Menu > Ctrl. panel >
Settings and Connection > Wireless LAN > Show WLAN availability.
If a WLAN is available,
is displayed.
WLAN wizard
Select Menu > Ctrl. panel > Connectivity > WLAN wiz..
The WLAN wizard helps you find and connect to a wireless LAN (WLAN). When you open
the application, your device starts to scan for available WLANs and lists them.
Select Options and from the following:
Refresh — Update the list of available WLANs.
146 Connectivity

Nokia E52 Specifications

General

Technology	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 900 / 2100
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
Dimensions	116 x 49 x 9.9 mm, 54 cc (4.57 x 1.93 x 0.39 in)
Weight	98 g (3.46 oz)
SIM	Mini-SIM
Display Type	TFT, 16M colors
Display Resolution	240 x 320 pixels, 4:3 ratio (~167 ppi density)
OS	Symbian OS 9.3, Series 60 v3.2 UI
Internal Memory	60MB
Alert types	Vibration; Downloadable polyphonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.0, A2DP
GPS	Yes, with A-GPS; Nokia Maps
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Talk time	Up to 8 h (2G) / Up to 6 h (3G)
Announced	2009, May
Display Size	2.4 inches
CPU	ARM 11
Card slot	microSDHC (dedicated slot)
Camera Single	3.2 MP
WLAN	Wi-Fi 802.11 b/g
Sensors	Accelerometer
Battery	Removable Li-Po 1500 mAh (BP-4L)
Stand-by	Up to 672 h (2G) / Up to 432 h (3G)
Colors	Metal Grey
SAR	0.79 W/kg (body)
