Table5
RRHfrequencyrangeandbandwidth(Cont.)
RF Module
variant
TX frequency
range
[MHz]
RX frequency
range
[MHz]
DL
instantaneous
bandwidth
[MHz]
UL
instantaneou
s bandwidth
[MHz]
DL filter
bandwidth
[MHz]
UL filter
bandwidth
[MHz]
RRH2x60W
900MHzFHDB
925-960 880-915 35 35 35 35
RRH2x40W
1800MHzFHEA
1805-1880 1710-1785
23
4)
25
5)
40 75 75
RRH2x60W
1800MHzFHEB
1805-1880 1710-1785
35/40
6)
40
7)
60 75 75
RRH2x60
W/4x30W1700
MHz/2100MHz
FRIG
2110-2155 1710-1755 45 45 45 45
RRH2x40W
2100FRGQ
2110-2170 1920-1980 20 60 60 60
RRH2x60W
2100FRGY
2110-2170 1920-1980 40 40 60 60
RRH4x30W
2600MHzFRHE
2620-2675 2500-2555 40 40 55 55
RRH4x30W
2600MHzFRHD
2640-2690 2520-2570 40 40 50 50
RRH2x40W
2600FRHB
2620-2690 2500-2570 20 20 70 70

6)
relevantforWCDMA/LTEwhensharedwithGSM
7)
relevantforWCDMAandLTE
