Nokia Flexi Multiradio BTS User Manual

Table10
DCCableRequirementsfor80WRFModules
Variant Total Configured
output power
8)
RET/MHA Minimum DC
voltage
Power
Cable
9)
2100/1900/18
00
(FRGT/FXFC/
FXEB)
<=180W Any Any Single
2100/1900/18
00
(FRGT/FXFC/
FXEB)
>180W Yes <46.5 Dual
2100/1900/18
00
(FRGT/FXFC/
FXEB)
>180W Yes >=46.5 Single
2100/1900/18
00
(FRGT/FXFC/
FXEB)
>180W No <41.5 Dual
2100/1900/18
00
(FRGT/FXFC/
FXEB)
>180W No >=41.5 Single
850/900
(FXCB/FXDB)
<=180W Any Any Single
850/900
(FXCB/FXDB)
>180W Yes <40 Dual
850/900
(FXCB/FXDB)
>180W Yes <46.5 Single
850/900
(FXCB/FXDB)
>180W Yes >=46.5 Single
850/900 >180W No <41.5 Single

8)
Totalconfiguredoutputpoweristhetotalpowerforallthreebranches.Forexample,a2+2+2@40Wis
equalto240W.
9)
Thefollowingpowercablesareavailable:FPCA472806A(Dual,2m,6.6ft),FPCB472817A(Single,2m,
6.6ft),FPCC472823A(Single,2m,6.6ft),FPTA472246A(Single,4m,13.1ft).Thedualpowercable
requirestwoavailablePWRoutputsontheSystemModuleorPDU(excludingPWRAUX).Itis
recommendedtousethenextavailableconnectorsinsequence.TheFPCCandFPTArequireremoving
theconnectorfromoneend.Considerfutureexpansionwhenchoosingsingleordualpowercables.
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Powerrequirementsandoutputpower
Issue:05 DN0951745 43
 
