Function Description Item ref
Cellular EM ASIC Gazoo/Pearl N2200
CMT memory Combo 128M NOR/128M M3 D3000
USB transceiver ISP1707 HS USB transceiver D4280
FM-radio with RDS BTHFMRDS2.2D discrete
Bluetooth
N6000
Bluetooth
WLAN WLAN Cost4 N6300
GPS GPS5350_ROM3.0 N6200
USB charger BQ21450 N1140
Keyboard + RGB led
driver
Lysti 9-channel LED driver N1301
Touch screen
controller
TSC2005 N1510
RF ASIC Vapaus 5.1 N7500
GSM PA 850/900/1800/1900 N7520
WCDMA PA I/IV/VIII N7540
Oscillator VCTCXO 38.4MHZ G7500
TCXO 19.2 MHz G4246
TCXO 38.4 MHz G6450
TCXO 16.368 G6200
Sleep clock Crystal 32.768kHz B2200
B4240
MicroSD reader X5210
SIM card reader X2700
eMMC 32 GB eMMC D5200
FM transmitter SI4713 N6150
Display backlight
driver
TK65604 N1350
Accelerometer 3-axis accelerometer N7001
Audio codec AIC34 dual audio codec N4040
Consumer IR
transmitter
CIR LED V1360
Ambient light sensor Digital ambient light sensor N1530 (main
flex)
Display connector 3.5” wide VGA display X1521 (main
flex)
Main camera
connector
5Mpix CMOS camera with
electronic shutter
X5800
RX-51
System Module
