Type Description
USB cable
GPS testing concept with GPS RF coupler
Figure 10 RF testing concept with RF coupler
Type Description
Product specific devices
FS-94 Flash adapter
SA-131 GPS RF coupler
Other devices
CU-4 Control unit
SX-4 Smart card
JXS-1 RF shield box
PK-1 SW security device
SS-62 Flash adapter base
Smart card reader
Measurement equipment
PC with Phoenix service software
Cables
RX-51
Service Tools and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –21
Copyright © 2009 Nokia. All rights reserved.
