Flash concept with FPS-21
Figure 4 Basic flash concept with FPS-21
Type Description
Product specific devices
FS-94 Flash adapter
Other devices
FPS-21 Flash prommer box
AC-35 Power supply
PK-1 SW security device
SS-46 Interface adapter
PC with Phoenix service software
Cables
CA-89DS Service cable
USB cable
CA-101 Micro USB cable
RX-51
Service Tools and Service Concepts
