T-Mobile High-Speed Internet Gateway Operator
Manual
ChapterTitleVariable
Issue: DRAFT Nokia 3TG-01275-AAAA-TCZZA 45
Figure 9 T-Mobile High-Speed Internet Gateway LCD screen
5.6.1 Connection
The Connection screen is the first that is displayed after on boarding is successful.
The Connection screen displays the RSRP of 4G/LTE and 5G signals. The title of the
screen is “CONNECTION”. The bars indicate the signal strength. The RSRP of 5G
signal is shown when there is only 5G connection (in SA mode). The strongest RSRP
signal (4G and 5G) are shown when both 4G and 5G connections are established.
Figure 10 5G and 4G connection
Note — Once you have a good signal, do not relocate or rotate
the T-Mobile High-Speed Internet Gateway. If the position of
the T-Mobile High-Speed Internet Gateway is changed, check
the signal strength again.
