Correcting Keystone
Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection.
To correct the problem:
• Adjust the projection angle or height of the projector.
• If the installation location of the projector does not allow for angle or height adjustment, you can use the Auto Keystone
function from the OSD menu.
 Go to: Home > Settings > Basic Settings > Keystone > Auto Keystone > select Enable.
• If you need to manually correct the image after the Auto Keystone adjustment:
1. Go to: Home > Settings > Basic Settings > Keystone > Auto Keystone > select Disable.
2. Press Up (
)/Down ( ) to highlight H Keystone, or V Keystone.
 Highlight V Keystone and press Left (
)/Right ( ) to correct the vertical keystone.
 Highlight H Keystone and press Left (
)/Right ( ) to correct horizontal keystone.
