Connection Ports
2
AUX
1 2 3
4 5 6 7 8 9
Port Description
1 Power Toggle Power On/O
2 Micro SD Micro SD socket (SDXC up to 256 GB - FAT32/NTFS)
3 Audio In or AUX (3.5 mm jack) 3.5 mm jack audio input socket
4 Audio Out (3.5 mm jack) 3.5 mm jack audio output socket
5 USB A (5V/2A Out) USB 2.0 Type A port (USB Reader - FAT32/NTFS)
6 IR Sensor IR sensor
7 HDMI HDMI port
8 USB-C USB-C port
9 DC In Power input socket
¹ Supports HDMI 1.4, HDCP 1.4.
² iPhone/iPad users will need to buy an additional adapter. To avoid compatibility issues, please use Apple authorized accessories.
³ Please use the supplied USB-C cable, and ensure your USB-C device can support video transmission as well as charging.
