87
Input
HDMI 1 (HDMI 1.4, HDCP 1.4)
SD Card Micro SD (Supports up to 256 GB, SDXC)
USB Type C 1 (5V/2A)
USB Type A 1 USB 2.0 Reader
Wi-Fi input 1 (5G, 802.11 a/b/g/n)
Audio In (3.5 mm) 1
Bluetooth input 1 (BT 4.2/Audio In)
Output
Audio Out (3.5 mm) 1
Bluetooth output 1 (BT 4.2/Audio Out)
Speaker
8W Cube x 2
(Tweeter + Woofer) x 2
USB Type A (Power) 1 (USB 2.0, 5V/2A, share with reader)
Power Adapter
Input Voltage DC IN 100-240V, 50/60 Hz (auto switch)
Operating Conditions
Temperature 0°C to 40°C (32°F to 104°F)
Humidity 0% to 90% (non-condensing)
Dimensions
Physical (W x H x D)
276 x 165 x 157 mm
(10.87” x 6.50” x 6.18”)
Default setup
276 x 165 x 171 mm
(10.87” x 6.50” x 6.73”)
With cone-
shaped feet
Weight
Physical 2.8 kg (6.17 lbs)
Power Consumption
On 90W (Typical)
O < 0.5W (Standby)
