6.1.9 STEP 9: Control System Test
↓ M 84 M
• Normal Operating Screen is shown above.
CAUTION!:
IN THE FOLLOWING PROCEDURE, SWITCH THE CONTROL
PANEL TO MANUAL MODE IMMEDIATELY IF THE BOOM
MOVEMENTS ARE ERRATIC.
• Toggle "AUTO (YES)" to start AUTO mode. Observe the behavior of
the booms while correcting to the target height.
↓A 115 A
• The operating screen shows the system is in AUTO mode and the target
height is 114 cm (45 inches).
• The boom movements should be smooth and stable. Boom corrections
should stop after a few seconds, under normal conditions (excessive
wind may cause small corrections to continue).
↓A 116 A
• Toggle the "MANUAL" switch to return to MANUAL mode.
• If the boom corrections are done in an acceptable manner your system is
ready to use.
Automatic System Setup Complete
