Installation and Owner’s Manual 20
- If the depth of the enclosure is 21 3/8 inches or more and is less than
22 3/8 inches [27], add two bafes [16] to the rear of the enclosure (See
Art02337 and Art02338).
- For model N3104, put one bafe 10 inches above the bottom of
the enclosure [17], or at the top of the lower intake vent opening,
whichever is higher.
- For model N3150, put one bafe 12 inches above the bottom of
the enclosure [17], or at the top of the lower intake vent opening,
whichever is higher.
- Put the other bafe at the lowest edge of the condenser [11] of the
refrigerator.
- Make sure that the bafes are 1 inch or less [19] from the coils
[10] and condenser [11] of the refrigerator.
- Make sure that the bafes are the full width of the inside of the
enclosure.
- If the depth of the enclosure is more than 22 3/8 inches [27], install a
wood or an aluminum or galvanized sheet solid box bafe [21] in the
rear of the enclosure (See Art02341 and Art02342).
- Make sure that the horizontal bottom of the solid box bafe is even
with or above the top edge of the lower exhaust vent [9].
- Make sure that distance from the enclosure oor to the vertical
bottom edge of the solid box bafe [17] is 10 in. for N3104 models and 12 in. for N3150
models.
- Make sure that the back of the solid box bafe is perpendicular to the bottom of the
enclosure.
- Make sure that the back of the solid box bafe is either against the top of the enclosure or
against the angled bafe [13] (depending on the vehicle design).
- Make sure that the solid box bafe is one inch or less [19] from the coils [10] and
condenser [11] of the refrigerator.
- Make sure that the solid box bafe is the full width of the inside of the enclosure.
9
17
27
10
19
21
11
13
12
14
Art02342
20
Art02340
22
23
