Norcold N4000 - Remove Slide-Out Box System; Remove Drawer; Check the Seal of the Doors

Installation and Owner’s Manual 10
Art00980
If either door does not seal correctly, excess frost will collect inside the refrigerator. Make
sure the doors seal correctly (See Art00980):
- Close each door on a piece of paper that is about the size and thickness of a dollar bill.
- Gently pull the paper.
- You should feel a slight drag between the gasket and the cabinet.
- Do this on all four sides of the door.
- If you do not feel a slight drag on the paper, the door does not seal correctly.
- Have your dealer or an authorized Norcold Service Center correct the seal of the
door.
Check the Seal of the Doors
NOTICE
Remove Slide out Box System (Art02596)
- Open the refrigerator door.
- Remove slide out box
- Slide the rail system to the right.
- Remove slide out box.
- Once area is clean, move the rail system to the left.
- Place the slide out box back into refrigerator.
Make sure the slide out box snaps into place.
Remove Drawer
- Open the refrigerator door
- Pull the drawer until it stops.
- Push it a little bit back and push the guide locks backwards. (See Art02616)
- Pull the drawer twoards you and lift the wheels over the curves. (See Art02599)
- Clean the desired area and place the drawer back into the refrigerator.
- Push the guide locks forward
- Tilt the drawer over the wheels.
- Push the drawer into the refrigerator.
ART 02596
ART 02599
ART 02616
