Norcold N4000 - Handling; Install the Refrigerator; Combustion Seal

Installation and Owner’s Manual 25
Handling
Only carry the refrigerator at the strap handles on top (1), if equipped. Do not use your knee to lift the refrigerator (2).
Install the Refrigerator
- Push the refrigerator completely into the enclosure.
- Use screws to x the refrigerator, and the white caps
for nishing.
- For the N4104, 4 screws and 4 white caps are
supplied.
- For the N4150, 6 screws and 6 white caps are
supplied.
- For the N4141, 6 screws and
6 white caps are supplied.
Combustion Seal
Position sealing as shown in the gure.
Fix the strips to the sides of the refrigerator (B) in a vertical direction at
the rear of the refrigerator.
Fix the upper and lower ap of the combustion sealing (A) as the
drawing shows.
Art02345
Art02348
Art02347
Art02349
Art02346
