Installation Manual 11
Put the refrigerator in position (See Art00962, Art00963, and Art00964):
Make sure the combustion seal [28] is not broken, is completely around
the refrigerator mounting anges, and is between the mounting anges
and the wall of the enclosure If the seal is not complete, exhaust fumes
can be present in the living area of the vehicle. The breathing of exhaust
fumes can cause dizziness, nausea, or in extreme cases, death.
- Push the refrigerator completely into the enclosure.
- Put the upper trim piece [40] onto the front of the refrigerator.
- Put screws [41] through the upper and lower mounting anges on the front of the refrigerator
and into the enclosure wall and oor.
- Put a cap [42] on each of the screw holes in the upper trim piece [40] on the front of the
refrigerator.
Do not omit the bottom trim piece. This piece is part of the combustion
seal.
- Push the bottom trim piece [29] onto the front of the refrigerator.
- Put two screws [41] through the trim piece, the mounting ange, and into the oor.
- Put screws through mounting ange on the rear of the refrigerator and into the oor.
Install the Refrigerator
Art00962
28
29
Art00963
41
42
40
41
29
41
WARNING
!
WARNING
!
To Next Page
