Norcold N81 Series Installation Manual

Installation Manual 2
Table of Contents
Safety Awareness
Safety Instructions
Safety Awareness ..................................................................................................................................................................................... 2
Safety Instructions ....................................................................................................................................................................................2
Certication and Code Requirements.......................................................................................................................................................3
Ventilation Requirements..........................................................................................................................................................................4
Key Refrigerator Dimensions....................................................................................................................................................................5
Assemble the Enclosure for the Refrigerator............................................................................................................................................5
Install the Lower and Upper Vents............................................................................................................................................................6
Install Decorative Door Panels ...............................................................................................................................................................10
Install the Refrigerator ............................................................................................................................................................................ 11
Reverse the Door Swing-Nonmetal Doors (optional) .............................................................................................................................12
Reverse the Door Swing-Metal Doors (optional) ....................................................................................................................................14
Connect the Electrical Components .......................................................................................................................................................16
Connect the 120 volts AC supply ....................................................................................................................................................16
Connect the 12 volts DC supply ......................................................................................................................................................16
Connect the Low Ambient Heater (optional) ...........................................................................................................................................17
Connect the Propane Gas Components.................................................................................................................................................17
Connect the propane gas supply system ........................................................................................................................................17
Examine the propane gas supply system for leaks ......................................................................................................................... 18
Ignition and Start Up ............................................................................................................................................................................... 18
Ignition and start up ......................................................................................................................................................................... 18
Do a test of the gas safety valve .....................................................................................................................................................19
Shut down - all models ....................................................................................................................................................................19
Display Codes ........................................................................................................................................................................................19
Fault Codes ...........................................................................................................................................................................................20
Read this manual carefully and understand the contents before you install the refrigerator.
Be aware of possible safety hazards when you see the safety alert symbol on the refrigerator and in this manual. A signal word follows
the safety alert symbol and identies the danger of the hazard. Carefully read the descriptions of these signal words to fully know their
meanings. They are for your safety.
This signal word means a hazard, which if ignored, can cause dangerous personal injury, death, or much
property damage.
This signal word means a hazard, which if ignored, can cause small personal injury or much property
damage.
- This refrigerator is not approved for use as a free standing refrigerator. It is equipped for the use of propane gas only
and can not be changed to use any other fuels (natural gas, butane, etc.).
- Incorrect installation, adjustment, alteration, or maintenance of this refrigerator can cause personal injury, property
damage, or both.
- Obey the instructions in this manual to install intake and exhaust vents.
- Do not install the refrigerator directly on carpet. Put the refrigerator on a metal or wood panel that extends the full
width and depth of the refrigerator.
WARNING
!
WARNING
!
CAUTION
!

Norcold N81 Series Specifications

General

Brand	Norcold
Model	N81 Series
Category	Refrigerator
Language	English
