-40- B1000 www.nord.com
[L] [L]

6.1
M1 M2 M3 M4 M5 M6

6.1
M1 M2 M3 M4 M5 M6
SK072.1
0,16 0,32 0,21 0,23 0,18 0,20
SK072.1 F
0,16 0,32 0,21 0,23 0,18 0,20
SK172.1
0,27 0,59 0,42 0,45 0,32 0,39
SK172.1 F
0,27 0,59 0,42 0,45 0,32 0,39
SK372.1
0,45 1,05 0,75 1,00 0,60 0,65
SK372.1 F
0,45 1,05 0,75 1,00 0,60 0,65
SK572.1
0,75 1,90 1,50 2,00 1,10 1,15
SK572.1 F
0,75 1,90 1,50 2,00 1,10 1,15
SK672.1
1,10 2,60 2,15 2,70 1,55 1,65
SK672.1 F
1,10 2,60 2,15 2,70 1,55 1,65
SK772.1
1,15 3,65 2,25 3,15 1,35 2,15
SK772.1 F
1,15 3,65 2,25 3,15 1,35 2,15
SK872.1
2,60 8,00 5,30 7,00 2,80 4,60
SK872.1 F
2,60 8,00 5,30 7,00 2,80 4,60
SK972.1
4,50 12,90 8,10 12,70 4,60 7,80
SK972.1 F
4,50 12,90 8,10 12,70 4,60 7,80
[L] [L]

6.1
M1 M2 M3 M4 M5 M6

6.1
M1 M2 M3 M4 M5 M6
SK373.1
0,45 1,05 0,75 1,00 0,60 0,65
SK373.1 F
0,45 1,05 0,75 1,00 0,60 0,65
SK573.1
0,75 1,90 1,50 2,00 1,10 1,15
SK573.1 F
0,75 1,90 1,50 2,00 1,10 1,15
SK673.1
1,10 2,60 2,15 2,70 1,55 1,65
SK673.1 F
1,10 2,60 2,15 2,70 1,55 1,65
SK773.1
1,95 3,50 3,20 2,90 2,25 2,95
SK773.1 F
1,95 3,50 3,20 2,90 2,25 2,95
SK873.1
4,05 7,60 6,85 6,55 5,00 6,55
SK873.1 F
4,05 7,60 6,85 6,55 5,00 6,55
SK973.1
7,40 12,20 11,10 11,60 8,00 10,90
SK973.1 F
7,40 12,20 11,10 11,60 8,00 10,90
[L]

6.1
M1 M2 M3 M4 M5 M6 M1 M2 M3 M4 M5 M6

6.1
B3 V6 B8 V5 B6 B7 B5 V3 B5I V1 B5II B5III
SK172
0,35 0,50 0,50 0,50 0,50 0,50 0,35 0,50 0,50 0,50 0,50 0,50
SK272
0,60 1,00 1,00 1,00 1,00 1,00 0,60 1,00 1,00 1,00 1,00 1,00
SK372
0,60 1,00 1,00 1,00 1,00 1,00 0,60 1,00 1,00 1,00 1,00 1,00
SK472
1,00 1,90 1,90 2,00 1,80 1,80 1,00 1,90 1,90 1,90 1,90 1,50
SK572
1,00 1,90 1,90 2,00 1,80 1,80 1,00 1,90 1,90 1,90 1,90 1,50
SK672
1,40 3,40 3,10 3,15 1,45 3,15 1,15 3,40 2,70 2,80 1,25 2,70
SK772
2,00 3,30 3,50 4,20 2,70 3,30 1,60 3,30 3,50 3,30 3,10 3,10
SK872
3,70 9,60 9,10 7,30 4,70 8,00 3,50 9,00 7,90 7,70 3,90 7,20
SK972
6,50 16,00 15,70 14,70 8,50 14,00 6,50 15,00 13,00 13,50 6,50 12,00
[L]
SK273
0,62 1,10 1,10 1,10 1,10 1,10 0,62 1,10 1,10 1,10 1,10 1,10
SK373
0,55 1,10 1,10 1,10 1,10 1,10 0,55 1,10 1,10 1,10 1,10 1,10
SK473
1,30 2,50 2,10 2,40 2,10 2,10 1,25 2,40 2,10 2,50 2,10 2,10
SK573
1,30 2,50 2,10 2,40 2,10 2,10 1,25 2,40 2,10 2,50 2,10 2,10
SK673
1,80 3,80 3,20 3,40 2,90 3,00 1,70 3,80 3,00 3,20 3,00 3,00
SK773
2,50 4,50 3,70 4,60 3,30 3,30 2,30 5,00 3,60 4,50 3,90 3,90
SK873
6,20 8,40 7,50 9,10 7,50 7,50 5,00 8,80 7,60 8,00 8,00 8,00
SK973
11,00 15,80 13,00 16,00 13,30 13,00 10,30 16,50 13,00 16,00 14,00 14,00
