2. Description of Gear Units
www.nord.com B1000 -7-
2. Description of gear units
2.1 Type designations and gear unit types
Helical gear units
SK 11E, SK 21E, SK 31E,SK 41E, SK 51E (single-stage)
SK 02, SK 12, SK 22, SK 32, SK 42, SK 52, SK 62N
(2-stage)
SK 03, SK 13, SK 23, SK 33N, SK 43, SK 53 (3-stage)
SK 62, SK 72, SK 82, SK 92, SK 102 (2-stage)
SK 63, SK 73, SK 83, SK 93, SK 103 (3-stage)
NORDBLOC helical gear units
SK 320, SK 172, SK 272, SK 372, SK 472, SK 572, SK 672,
SK 772, SK 872, SK 972 (2-stage)
SK 273, SK 373, SK 473, SK 573, SK 673, SK 773, SK 873,
SK 973 (3-stage)
SK 072.1, SK 172.1, SK 372.1, SK 572.1, SK 672.1, SK 772.1
SK 872.1, SK 972.1 (2-stage)
SK 373.1, SK 573.1, SK 673.1, SK 773.1, SK 873.1,
SK 973.1 (3-stage)
Standard helical gear units
SK 0, SK 01, SK 20, SK 25, SK 30, SK 33 (2-stage)
SK 010, SK 200, SK 250, SK 300, SK 330 (3-stage)
Parallel shaft gear units
SK 0182NB, SK 0282NB, SK 1282, SK 2282, SK 3282,
SK 4282, SK 5282, SK 6282, SK 7282, SK 8282, SK 9282,
SK 10282, SK 11282 (2-stage)
SK 1382NB, SK 2382, SK 3382, SK 4382, SK 5382,
SK 6382, SK 7382, SK 8382, SK 9382, SK 10382,
SK 11382, SK 12382 (3-stage)
Bevel gear units
SK 92072, SK 92172, SK 92372, SK 92672, SK 92772
(2-stage)
SK 9012.1, SK 9016.1, SK 9022.1, SK 9032.1,
SK 9042.1, SK 9052.1, SK 9062.1, SK 9072.1,
SK 9082.1, SK 9086.1, SK 9092.1, SK 9096.1 (3-stage)
SK 9013.1, SK 9017.1, SK 9023.1, SK 9033.1, SK 9043.1,
SK 9053.1 (4-stage)
Contrate worm gear unit
SK 02040, SK 02050, SK 12063, SK 12080,
SK 32100,SK 42125 (2-stage)
SK 13050, SK 13063, SK 13080, SK 33100, SK 43125
(3-stage)
MINIBLOC worm gear units
SK1 S32, SK1 S40, SK 1S50, SK 1S63, SK 1SU...
SK 1SM31, SK 1SM40, SK 1SM50, SK 1SM63 (single-stage)
SK 2S32NB, SK 2S40NB, SK 2S50NB, SK 2S63NB,
SK 2SU…,
SK 2SM40, SK 2SM50, SK 2SM63 (2-stage)
UNIVERSAL worm gear units
SK 1SI31, SK 1SI40, SK 1SI50, SK 1SI63, SK 1SI75,
SK 1SIS31,…, SK 1SIS75,
SK 1SD31, SK 1SD40,SK 1SD50, SK 1SD63,
SK 1SIS-D31,…, SK 1SIS-D63 (single-stage)
SK 2SD40, SK 2SD50, SK 2SD63, SK 1SI…/31,
SK 1SI…/H10,
SK 2SIS-D40,…, SK 2SIS-D63 (2-stage)
Versions / Options
- Foot mounting with solid shaft
A Hollow shaft version
V Solid shaft version
L Solid shaft both sides
Z Drive flange B14
F Output flange B5
X Foot mounting
XZ Base and output flange B14
XF Base and output flange B5
AL Reinforced axial drive bearings
5 Reinforced output shaft
(Standard helical gear unit)
V Reinforced drive shaft
(Standard helical gear unit)
D Torque support
K Torque console
S Shrink disc
VS Reinforced shrink disc
EA Hollow shaft with internal spline
G Rubber buffer
VG Reinforced rubber buffer
R Back stop
B Fixing element
H Covering cap as contact guard
H66 Covering cap IP66
VL Reinforced bearings
VLII Agitator design
VLIII Drywell agitator design
IEC Standard motor mounting
NEMA Standard motor mounting
W With free drive shaft
VI Viton radial seals
OA Oil expansion vessel
OT Oil level tank
SO1 Synthetic oil ISO VG 220
CC Casing cover with cooling spiral
DR Spring Loaded Breather
H10 Modular contrate pre-stage
/31 Worm pre-stage
/40 Worm pre-stage
Double gear units consist of two single gear units. They are to be treated as per the instructions in
this Manual, i.e. as two individual gear units. Type designation of double gear units: e.g. SK 73/22
(consisting of single gears SK 73 and SK 22)
