SK 500E – Brief instructions for frequency inverters
32 BU 0540 EN-1516
3.2 Overview of technology units
Detailed information about the options listed below can be found in the relevant documentation.
Control boxes
Module Name Description Data Part No. Document
SK CSX-0 SimpleBox Commissioning,
parameterisation and
control of the
frequency inverter
7-segment, 4-digit
LED display,
single button
control
275900095 BU 0500
SK TU3-CTR ControlBox As for SK CSX-0
+ saving of the
parameters of an
inverter
7-segment, 4-digit
LED display,
keyboard
275900090 BU 0040
SK TU3-PAR ParameterBox As for SK CSX-0
+ saving of
parameters from up
to 5 inverters
(illuminated),
keyboard
275900100 BU 0040
SK TU3-POT PotentiometerBox Direct contol of the FI
0…100%
275900110 BU 0500
Table 8: Overview of Technology Units and Control Boxes
Interfaces
Module Interface Data Part No. Document
Normal field bus protocols
SK TU3-AS1 AS Interface 4 sensors / 2 actuators
5/8 pin screw terminals
275900170 BU 0090
SK TU3-CAO CANopen Baud rate 1 Mbit/s
Connector: Sub-D9
275900075 BU 0060
SK TU3-DEV DeviceNet Baud rate: 500 KBit/s
5-pole screw terminal
275900085 BU 0080
SK TU3-IBS InterBus Baud rate: 500 kBit/s (2Mbit/s)
Connector: 2 x Sub-D9
275900065 BU 0070
SK TU3-PBR Profibus DP Baud rate: 1.5 MBaud
Connector: Sub-D9
275900030 BU 0020
SK TU3-PBR-
24V
Profibus DP Baud rate: 12 MBaud
Connector: Sub-D9
24V DC connection via terminal
275900160 BU 0020
