SK 500E – Brief instructions for frequency inverters
6 BU 0540 EN-1516
1 General
Pos: 20 /A nl eitu nge n/El ek tro nik/FU u nd S tarter /1. Al lgemei nes/Ü ber blic k -1- [SK 5 xxE] @ 0\mod_1325779961835_388.docx @ 5316 @ 2 @ 1
1.1 Overview
Properties of the basic frequency inverter SK 500E:
• High starting torque and precise motor speed control setting with sensorless current vector
control
• Can be mounted next to each other without additional spacing
• Permissible ambient temperature range 0 to 50°C (please refer to the technical data)
• Frequency inverters Type SK 5xxE … -A: Integrated EMC mains filter for limit curve A1 (and
B1 for inverters Size 1 - 4) according to EN 55011, Category C2 (and C1 for inverters Size 1 - 4)
according to EN 61800-3 (not for 115 V inverters)
• Frequency inverters Type SK 5xxE … -O: without integrated EMC mains filter.
• Automatic measurement of the stator resistance or determination of the precise motor data
• Programmable direct current braking
• Integrated brake chopper for 4 quadrant operation (optional brake resistors)
• Four separate online switchable parameter sets
• RS232/485 interface via RJ12 plug connector
• Integrated USS and Modbus RTU (see BU 0050
)
Feature SK … 50xE 51xE 511E 520E 53xE 54xE
Additional
options
Operating manual BU 0500
BU
0505
Safe pulse block (STO / SS1)* x x x x BU 0530
2 x CANbus/CANopen interfaces via RJ45
plug
x x x x BU 0060
RS485 interface additionally via terminals
x
x
x
Speed feedback via incremental encoder
input
x x x
Integrated “POSICON” positioning control
x
x
BU 0510
CANopen absolute encoder evaluation x x BU 0510
PLC / SPS – functionality
x
x
x
BU 0550
Universal encoder interface
(SSI, BISS, Hiperface, EnDat and SIN/COS)
x BU 0510
Operation of PM synchronous motors
(Permanent Magnet Synchronous Motors)
x x x x x x
Number of digital inputs / outputs** 5 / 0 5 / 0 5 / 0 7 / 2 7 / 2
5 / 3 6 / 2
7 / 1
Additional potential-isolated PTC input***
x
Number of analog inputs / outputs 2 / 1 2 / 1 2 / 1 2 / 1 2 / 1 2 / 1
Number of relay messages
2
2
2
2
2
2
* not with 115 V devices
** SK 54xE: 2 I/Os can be variably parameterised as inputs or outputs
*** alternative "thermistor" function on digital input 5 possible (above size 5 an additional thermistor input is available as
standard)
Table 2: Overview of SK 500E performance grading features
