5 Parameters
BU 0540 EN-1516 41
Parameter
No. [Array]
Designation
Factory
setting
Supervisor
Setting after commissioning
P 1
P 2
P 3
P 4
P405 (P)
Function Analogue input 2
0
P406
Analog input mode 2
0
S
P407
Adjustment 2: 0% [V]
0.0
S
P408
Adjustment 2: 100% [V]
10.0
S
P409
Filter On input 2 [ms]
100
S
P410 (P)
Min. Freq. Auxiliary setpoint [Hz]
0.0
P411 (P)
Max. Freq. Auxiliary setpoint [Hz]
50.0
P412 (P)
Setpoint process controller [V]
5.0
S
P413 (P)
PID control P comp [%].
10.0
S
P414 (P)
PID control I-component [%/ms]
10.0
S
P415 (P)
PID control D-component [%/ms]
1.0
S
P416 (P)
Ramp time PI setpoint [s]
2.0
S
P417 (P)
Analog output offset 1 [V]
0.0
S
P418 (P)
Function Analogue output 1
0
P419 (P)
Standard Analogue output 1 [%]
100
P420
Digital input 1 (DIN1)
1
P421
Digital input 2 (DIN2)
2
P422
Digital input 3 (DIN3)
8
P423
Digital input 4 (DIN4)
4
P424
Digital input 5 (DIN5)
0
P425
Digital input 6 (DIN6)
0
P426 (P)
Emergency stop time [s]
00:10
P427
Emerg. stop Fault
0
S
P428 (P)
Automatic starting
0 (off)
S
P429 (P)
Fixed frequency 1 [Hz]
0.0
P430 (P)
Fixed frequency 2 [Hz]
0.0
P431 (P)
Fixed frequency 3 [Hz]
0.0
P432 (P)
Fixed frequency 4 [Hz]
0.0
P433 (P)
Fixed frequency 5 [Hz]
0.0
P434 (P)
Relay 1 function (K1)
1
P435 (P)
Relay 1 scaling [%]
100
P436 (P)
Relay 1 hysteresis [%]
10
S
P441 (P)
Relay 2 function (K2)
7
P442 (P)
Relay 2 scaling [%]
100
P443 (P)
Relay 2 hysteresis [%]
10
S
P450 (P)
Relay 3 function (DOUT1)
0
P451 (P)
Relay 3 scaling [%]
100
P452 (P)
Relay 3 hysteresis [%]
10
S
P455 (P)
Relay 4 function (DOUT2)
0
P456 (P)
Relay 4 scaling [%]
100
P457 (P)
Relay 4 hysteresis [%]
10
S
P460
Watchdog time [s]
10.0
S
P461
Function 2 Encoders
0
P462
Pulse number 2 Encoder [Imp.]
1024
P463
2nd rotary encoder ratio
01:00
P464
Fixed frequency mode
0
P465 [-01]
Fixed frequency / Array 01
0
P465 [-02]
Fixed frequency / Array 02
0
P465 [-03]
Fixed frequency / Array 03
0
P465 [-04]
Fixed frequency / Array 04
0
P465 [-05]
Fixed frequency / Array 05
0
P465 [-06]
Fixed frequency / Array 06
0
P465 [-07]
Fixed frequency / Array 07
0
P465 [-08]
Fixed frequency / Array 08
0
P465 [-09]
Fixed frequency / Array 09
0
P465 [-10]
Fixed frequency / Array 10
0
P465 [-11]
Fixed frequency / Array 11
0
P465 [-12]
Fixed frequency / Array 12
0
P465 [-13]
Fixed frequency / Array 13
0
P465 [-14]
Fixed frequency / Array 14
0
P465 [-15]
Fixed frequency / Array 15
0
P465 [-16]
Fixed frequency / Array 16
0
