Nord Drivesystems SK 511E Series User Manual

5 Parameters
BU 0540 EN-1516 43
Parameter
No. [Array]
Designation
Factory
setting
Supervisor
Setting after commissioning
P 1
P 2
P 3
P 4
P483 [-06]
Hyst. Bus I/O Out Bits [%]
10
S
P483 [-07]
Hyst. Bus I/O Out Bits [%]
10
S
P483 [-08]
Hyst. Bus I/O Out Bits [%]
10
S
P483 [-09]
Hyst. Bus I/O Out Bits [%]
10
S
P483 [-10]
Hyst. Bus I/O Out Bits [%]
10
S
Extra functions
P501
Inverter name
0
P502 [-01]
Master function value 1
0
S
P502 [-02]
Master function value 2
0
S
P502 [-03]
Master function value 3
0
S
P503
Leading function output
0
S
P504
Pulse frequency [kHz]
6.0/4.0
S
P505 (P)
Abs. minimum frequency [Hz]
2.0
S
P506
Auto. Fault acknowledgement
0
S
P507
PPO-Type
1
P508
Profibus address
1
P509
Control word source
0
P510 [-01]
Setpoint source (Main Setpoint)
0 (auto)
S
P510 [-02]
Setpoint source (Auxiliary Setpoint)
0 (auto)
S
P511
USS baud rate
3
S
P512
USS address
0
P513
Telegram time-out [s]
0.0
S
P514
CAN bus baud rate
4
P515 [-01]
CAN address (reception)
50
P515 [-02]
CAN address (BC - reception)
50
P515 [-03]
CAN address (BC - transmission)
50
P516 (P)
Skip frequency 1 [Hz]
0.0
S
P517 (P)
Skip frequency range 1 [Hz]
2.0
S
P518 (P)
Skip frequency 2 [Hz]
0.0
S
P519 (P)
Skip frequency range 2 [Hz]
2.0
S
P520 (P)
Flying start
0
S
P521 (P)
Flying start resolution [Hz]
00:05
S
P522 (P)
Flying start offset [Hz]
0.0
S
P523
Factory setting
0
P525 [-01] (P)
Max. load monitoring max. 1 [%]
401 (Off)
S
P525 [-02] (P)
Max. load monitoring max. 2 [%]
401 (Off)
S
P525 [-03] (P)
Max. load monitoring max. 3 [%]
401 (Off)
S
P526 [-01] (P)
Min. load monitoring 1 [%]
0 (off)
S
P526 [-02] (P)
Min. load monitoring 2 [%]
0 (off)
S
P526 [-03] (P)
Min. load monitoring 3 [%]
0 (off)
S
P527 [-01] (P)
Load monitoring Freq. 1 [Hz]
25
S
P527 [-02] (P)
Load monitoring Freq. 2 [Hz]
25
S
P527 [-03] (P)
Load monitoring Freq. 3 [Hz]
25
S
P528 (P)
Load monitoring delay [s]
02:00
S
P529 (P)
Mode Load control
0
S
P533
Factor I
2
t-Motor [%]
100
S
P534 [-01] (P)
Torque disconnection limit [%]
401 (Off)
S
P534 [-02] (P)
Torque disconnection limit [%]
401 (Off)
S
P535
I
2
t-Motor
0
S
P536
Current limit
1.5
S
P537
Pulse switch-off [%]
150
S
P538
Mains voltage Monitoring
3
S
P539 (P)
Output monitoring
0
S
P540
Mode phase sequence
0
S
P541
Set relay [hex]
0000
S
P542
Set analog output [V]
0.0
S
P543 (P)
Actual bus value 1
1
S
P544 (P)
Actual bus value 2
0
S
P545 (P)
Actual bus value 3
0
S
P546 (P)
Function Bus setpoint 1
1
S
P547 (P)
Function Bus setpoint 2
0
S
