SK 500E – Brief instructions for frequency inverters
46 BU 0540 EN-1516
Parameter
No. [Array]
Designation Actual status and displayed values
INFORMATION, read only
P708
Status of digital input (bin/hex)
P709
Voltage, analog input 1 [V]
P710
Analogue output volt. [V]
P711
Relay status [hex]
P712
Voltage, analog input 2 [V]
P714
Operating period [h]
P715
Enable period [h]
P716
Actual frequency [Hz]
P717
Actual speed [rpm]
P718
Present Setpoint frequency 1..3
[Hz]
P719
Actual current [A]
P720
Present Actual torque current [A]:
P721
Actual field current [A]
P722
Actual voltage [V]
P723
Voltage-d [V]
P724
Voltage-q [V]
P725
Actual cos phi
P726
Apparent power [kVA]
P727
Mechanical power [kW]
P728
Input voltage [V]
P729
Torque [%]
P730
Field [%]
P731
Parameter set
P732
U phase current [A]
P733
V phase current [A]
P734
W phase current [A]
P735
Speed encoder [rpm]
P736
Link voltage [V]
P737
Current utilisation of brake
resistor [%]
P738
Actual utilisation of motor [%]
P739
Heat sink temperature [°C]
P740
Process data Bus In 1…13 [hex]
P741
Process data Bus Out 1…13 [hex]
P742
Data base version
P743
Inverter ID
P744
Configuration
P745
Module version
P746
Module status
P747
Inverter voltage range 230/400V
P748
CANopen status
P750
Stat. overcurrent
P751
Stat. overvoltage
P752
Stat. Mains fault
P753
Stat. overtemperature
P754
Stat. Param. loss
P755
Stat. System error
P756
Stat. timeout
P757
Stat. customer error
P799
Op.-time last error 1...5
