6 Operating status messages
BU 0540 EN-1516 55
Switch-on block messages
Display in the
SimpleBox /
ControlBox
Reason:
Text in the ParameterBox
Cause
• Remedy
Group Details in
P700 [-03]
Pos: 483 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 000 _01 [S K 18 0E ... SK 5 xxE] @ 2\mod_1347457775195_388.docx @ 47347 @ @ 1
I000
0.1 Disable voltage from IO
If the function "disable voltage"is parameterised, input (P420
/ P480) is at Low
• Set "input High"
• Check signal cable (broken cable)
0.2 IO fast stop
If the function "fast stop"is parameterised, input (P420 /
P480) is at Low
• Set "input High"
• Check signal cable (broken cable)
0.3 Block voltage from bus
• For bus operation (P509): control word Bit 1 is
"Low"
0.4 Bus fast stop
• For bus operation (P509): control word Bit 2 is
"Low"
0.5 Enable on start
Enable signal (control word, Dig I/O or Bus I/O) was already
applied during the initialisation phase (after mains "ON", or
control voltage "ON"). Or electrical phase is missing.
•
Only issue enable signal after completion of
initialisation (i.e. when the FI is ready)
• Activation of "Automatic Start" (P428)
0.6 – 0.7 Reserved
Information message for PLC see supplementary
instructions
Pos: 48 4 /Anlei tung en/El ektr onik/FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 000 _02-Er gänz ung 08 und 09 [SK 180E ... SK 5xxE] @ 10\mod_1455725649528_388.docx @ 306332 @ @ 1
0.8 Right direction blocked
Switch-on block with inverter shut-off activated by:
P540 or by "Enable right block" (P420 = 31, 73) or "Enable
left block" (P420 = 32, 74),
The frequency inverter switches to "Ready for switching on"
status
0.9 Left direction blocked
Pos: 48 5 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Bet rie bsz ust and /Stör m eldung en (A ufli stung )/I nf or matio n I 006 [SK 180 E .. . SK 5x xE] @ 2 \mod_1347457929759_388.docx @ 47372 @ @ 1
I006
6.0 Charging error
Charging relay not energised, because:
•
Mains / link voltage too low
•
Mains failure
•
Evacuation run activated ((P420) / (P480))
Pos: 486 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf or mati on I 011 [SK 180E . .. SK 5xxE ] @ 2 \mod_1347457936856_388.docx @ 47397 @ @ 1
I011
11.0 Analog Stop
If an analog input of the frequency inverter or a connected
IO extension is configured to detect cable breaks (2-10V
signal or 4-20mA signal), the frequency inverter switches to
the status "ready for switch-on" if the analog signal
undershoots the value 1 V or 2 mA
This also occurs if the relevant analog input is
parameterised to function "0" ("no function").
• Check connections
Pos: 487 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Inf ormation I014 "reserviert" [SK 200E ... SK 5xxE] @ 2\mod_1347457944329_388.docx @ 47422 @ @ 1
I014
14.4 Reserved
Error message for POSICON see supplementary
instructions
Pos: 48 8 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebs zus ta nd/S tör mel dung en (Auf list ung )/I nfor ma tio n I0 18 "r es ervi ert" [S K 2 xxE/ SK 5 xxE ] @ 2\mod_1347457946544_388.docx @ 47447 @ @ 1
I018
18.0 Reserved
Information message for "Safe Stop" function see
supplementary instructions
