Measuring current
Figure 29: Current measurement with a current meter
Note: Use a high-speed, high-dynamic-range ampere meter for the best and most reliable
measurements. Current range switching in the current meter may affect the power supply to
the nRF9160. High speed and bandwidth is required to detect rapid changes in the current
consumption in the nRF9160.
4418_1216 v0.7
33
