Introduction
The nRF9160 DK (Development Kit) is a hardware development platform to be used for the design and
development of application firmware on the nRF9160 LTE Cat-M1 and Cat-NB1 System in Package (SiP).
The board includes all necessary external circuitry like a SIM card holder and an antenna and it provides
developers access to all I/O pins and relevant module interfaces.
Note: The DK can be connected to a base station by the onboard LTE antenna or to an LTE
emulator by an RF cable. See our nRF9160 Certifications webpage to find the bands supported
by the LTE modem. If no SIM card is inserted, the DK cannot initiate communication with the LTE
network.
The key features of the development kit are:
• nRF9160 SiP
• LTE antenna that supports all bands supported by the SiP
• Global Positioning System (GPS) antenna
• nRF52840 as a board controller and network processor for Bluetooth
®
and IEEE 802.15.4 protocols
• Buttons, switches, and LEDs for user interaction
• I/O interface for Arduino form factor plug-in modules
• SEGGER J-Link OB Debugger with debug out functionality
• UART interface through virtual COM port
• USB connection for debug/programming and power
• SIM card socket for nano-SIM (4FF SIM)
• Interfaces for nRF9160 current consumption measurements
Note: nRF9160 DK is compliant with the PS1 classification according to the IEC 62368-1 standard.
Skilled person: Person with relevant education or experience to enable him or her to identify hazards and
to take appropriate actions to reduce the risks of injury to themselves and others.
4418_1216 v0.7
5
