5
PART IDENTIFICATION CHART
See the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if
i
t has been preassembled. To avoid damaging parts, do not use power tools for assembly.
M4 x 16mm
Screw (90)–6
M
M10 x 95mm Patch
Screw (76)–4
M8 x 20mm
Patch Screw
(74)–4
M8 Split
Washer (75)–8
M8 Washer
(43)–2
M8 Locknut
(72)–4
M6 x 60mm Bolt Set (51)–1
M6 x 70mm Bolt Set (50)–1
M4 x 22mm
Screw (94)–2
M4 x 5mm
Patch Screw
(91)–1
To Next Page
