NordicTrack GX 4.4 PRO User Manual

11
10
9. Remove the Seat Knob (26) from the Seat
Bracket (30) inside the Seat Carriage (24).
Next, hold the Seat Carriage (24) on the Seat
Post (6). Insert the Seat Knob (26) upward into
the Seat Post, and tighten the Seat Knob into the
Seat Bracket (30) inside the Seat Carriage.
9
26
24
6
28
27
6
10. Loosen the Seat Post Knob (27) and pull it out-
ward. Next, insert the Seat Post (6) into the Seat
Post Sleeve (28), and then release the Seat Post
Knob. Move the Seat Post upward or down-
ward slightly to make sure that the Seat Post
Knob is engaged in one of the adjustment
holes in the Seat Post. Then, tighten the Seat
Post Knob.
30

NordicTrack GX 4.4 PRO Specifications

General

Type	Upright
Workout Programs	20
Weight Capacity	300 lbs
Adjustable Seat	Yes
iFit Compatibility	Yes
Resistance Type	Magnetic
Display Type	Backlit LCD
Flywheel Weight	18 lbs
Heart Rate Monitoring	EKG Grip Pulse
Display	5-inch Backlit Display
