11
6
91
92
94
6. Connect the Handrail Wire (91) to the Upright
Wire (92). For your treadmill to function
properly, make sure to connect the wires as
described in step 2. Then, insert the wires into
the Right Upright (94).
7
7. Identify the Right Handrail Cover (84). Insert the
front edge of the Right Handrail Cover into the
top of the handrail assembly (E) on the right side
of the treadmill as shown. Then, press down on
the top of the Right Handrail Cover until it snaps
into place.
Attach the Left Handrail Cover (83) to the left
side of the handrail assembly (E) in the same
way.
E
83
84
To Next Page
