NordicTrack STRENGTH CIRCUIT TRAINER User Manual

8
8. Wrap the Hack Squat Cable (29) under a 3 1/2”
Pulley (27). Attach the Pulley to the indicated
bracket on the Hack Squat Base (1) with an M10 x
46mm Button Head Bolt (40) and an M10 Nylon
Locknut (51).
10. Wrap the Hack Squat Cable (29) over a 3 1/2”
Pulley (27). Attach the Pulley to the second set of
holes from the bottom of the indicated bracket on
the Hack Squat Top Frame (6) with an M10 x
46mm Button Head Bolt (40) and an M10 Nylon
Locknut (51).
9. Wrap the Hack Squat Cable (29) under a 3 1/2”
Pulley (27). Attach the Pulley to the indicated
bracket on the Hack Squat Base (1) with an M10 x
78mm Button Head Bolt (41). Do not attach a
locknut yet.
9
8
41
6
29
27
1
10
51
1
40
27
51
29
11.Attach the Hack Squat Cable (29) to the Eyebolt
(G) with a Spring Clip (H).
11
G
H
29
40
29
27
