6
#8 x 3/4" Screw
(6)–12
Bullone 3/8" x 2" (2)–2
3/8" x 3 1/2" Screw (9)–4
Vite 3/8" x 4" (3)–6
5/16" x 1"
Screw (7)–2
Vite 5/16" x 2 3/4" (12)–4
5/16" Flat
Washer (XX)–4
Rondella a Stella
5/16" (8)–4
#8 x 3/4" Tek
Screw (13)–8
Rondella a Stella
#10 (5)–4
Rondella a Stella
3/8" (10)–6
Dado 3/8" (9)–4
Vite #8 x 1/2" (1)–14
Vite #10 x 3/4" (4)–4
Bullone 3/8" x 2 1/2" (7)–2
TABELLA IDENTIFICAZIONE PEZZI
Fare riferimento ai disegni sottostanti per identificare i pezzi utilizzati durante il montaggio. Il numero tra paren-
tesi indicato in ogni disegno rappresenta il numero pezzo, evinto dall’ELENCO PEZZI al termine del presente
manuale. Il numero dopo le parentesi è la quantità necessaria per il montaggio. Nota: qualora un pezzo non sia
rintracciabile nel kit hardware, verificare se sia stato preassemblato. Nella confezione possono essere
inclusi pezzi di scorta.
