NordicTrack T 7.0 Treadmill User Manual

13
13. Set the console assembly on the Left and Right
Handrails (79, 83). Make sure that no wires
are pinched. Insert the excess Upright Wire (91)
behind the Console Frame (101).
Attach the console assembly to the brackets on
the Handrails (79, 83) with the four 5/16" x 5/8"
Screws (11) that you removed in step 9. Start all
four Screws, but do not tighten them yet.
13
83
Console
Assembly
11
11
91
79
14. Attach the Pulse Crossbar (81) to the console
assembly with six #8 x 1/2" Screws (1). Start all
six Screws, and then tighten them.
Firmly tighten the four 5/16" x 5/8" Screws (11).
See steps 4 and 5. Tighten all six 3/8" x 4"
Screws (3).
14
81
Console
Assembly
11
11
1
1
1
101
