M8 Locknut
(43)–4
M8 Washer
(64)–4
M8 x 16mm
Screw (63)–4
M10 x 15mm
Screw (65)–4
M10 Washer
(31)–4
Tablet Holder
Screw (69)–4
#8 x 18mm
Screw (34)–8
M10 x 110mm
Screw (53)–4
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see
whether it has been preassembled. Extra parts may be included.
