7
Assembly requires two persons.
Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you nish all assembly steps.
Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
To identify small parts, see page 6.
In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one adjustable wrench
Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
ASSEMBLY
1
2. Identify the Front Stabilizer (2), and orient it as
shown.
Attach the Front Stabilizer (2) to the Frame (1)
with two M10 x 110mm Screws (53).
53
1
2
2
1. Go to my.nordictrack.com on your computer
and register your product.
documents your ownership
activates your warranty
ensures priority customer support if assistance
is ever needed
Note: If you do not have internet access, call
Customer Care (see the front cover of this
manual) and register your product.
