Nordson ColorMax Operator Card

3
Color Change
To perform a color change in the shortest time
possible, two operators must be present. A single
operator could perform the entire process, but it
would take longer. The operators are responsible for
cleaning the following items:
S Operator A: Interior of the booth canopy and
cyclones
S Operator B: Powder feed center
The two operators’ tasks should be performed at the
same time. Unless otherwise noted, do not move on
to the next procedure until both operators’ tasks have
been completed.
Use the following procedures to perform a color
change in the Colormax booth. Perform all of the
applicable steps in each procedure.
NOTE: When a procedure affects both operators, it
is shown straddling both operator’s columns in the
following table.
Tasks
Procedure Operator A
See Figure 2
Operator B
See Figure 3
1 Close the booth doors and, if applicable, move the booth offline.
2 From the Auto Menu, touch the COLOR MENU button to access the Color Change Control
menu. Touch the INITIATE, B-OFF Start button. The system automatically performs the
following tasks:
NOTE: Perform procedure 3 while the system is performing these tasks.
NOTE: The INITIATE, B-OFF Stop button interrupts the gun blow-off cycle.
S Oscillators (if used) stop and the spray guns move in to the fully extended position.
S Feed center’s sieve, fluidizing air, and vibrating table stop, and the lance assembly raises.
S In/out gun positioners retract (one at a time) and powder is blown off the spray guns.
When the gun blow-off cycle is complete, the COLOR CHANGE CYCLE DONE indicator
flashes.
3 1. Disengage the coupling connecting the
reclaim conveyor line (9) to the reclaim
port (8).
2. Open the transfer pan (5) and blow out all
powder remaining in the pan.
3. Send three cleaning sponges through the
reclaim conveyor line.
NOTE: Do not close the transfer pan at this
time.
1. Unclamp the underpan (3) and turn it
counterclockwise until the chute is directly
over the chute on the back wall of the
powder feed center.
NOTE: If you are using the optional fluidizing
hopper, disconnect the air tubing before
removing the hopper from the feed center.
2. Remove the powder source from the feed
center.
Continued...
