Nordson ColorMax Operator Card

7
Tasks
Procedure Operator A
See Figure 2
Operator B
See Figure 3
7 1. Remove the plug from the scrap port (6),
blow off the plug, and set it aside.
2. Blow out any powder remaining in the
transfer pan (5), being careful not to get
any powder into the reclaim conveyor
line (9).
3. Install the plug into the reclaim port (8).
4. Open the cyclone access doors (3).
5. Blow off all interior surfaces of the
cyclones.
6. Depending on whether the system will be
operating in either spray-to-reclaim or
spray-to-waste mode, follow one of these
procedures:
Spray-to-Reclaim Mode Operation:
a. Close and latch the cyclone access
doors (3).
b. Close and latch the transfer pan (5).
c. Install the scrap conveyor line (7) onto
the scrap port (6).
Spray-to-Waste Mode Operation:
Leave the cyclone access doors (3) and
transfer pan (5) open.
NOTE: Each color must have a dedicated
reclaim filter element. Using a filter element
for multiple colors will result in cross
contamination.
1. Install the appropriate color-specific
reclaim filter element and install the
reclaim filter assembly (6) into the reclaim
receiver (5).
2. Rotate the reclaim receiver so that it is in
the upright position.
3. Connect the amplifier hose, pulse air
tubing, and reclaim conveyor line to the
reclaim receiver.
4. Touch the Sure Max Door Close button to
close the reclaim receiver discharge door.
NOTE: If your system has the optional
Vibrasonic sieve screen, unplug the Vibrasonic
transducer cable from its support bracket and
use caution when cleaning around the screen’s
Vibrasonic transducer.
5. Remove the sieve deck (1) and screen (2).
S Similar Shade Color Change: Blow
off the sieve screen.
S Different Shade Color Change: Set
the sieve screen aside and clean it
later. Install a clean sieve screen.
6. Blow off the sieve deck and underpan (3).
Turn the underpan clockwise until the
chute is directed toward the lance
assembly (7).
7. Install the appropriate sieve screen and the
sieve deck, and connect the Vibrasonic
transducer cable (if applicable).
8. Touch the Sure Max Disabled button to
enable the Sure Max powder transfer
system. Turn the vacuum diverter handle
to the fully counterclockwise position.
S Similar Shade Color Change: Install the
powder source into the feed center and
connect the fluidizing air tubing (if
applicable).
S Different Shade Color Change: Do not
install a new powder source until the end of
procedure 8.
Continued...
