Encore Manual Spray Gun Upgrade Kit
7
Part 1102654A
E 2010 Nordson Corporation
19. Gently fold the trigger switch ribbon cable and other connectors into the
gun, and install the display module onto the gun.
20. See Figure 1. Slide the hook (10) onto the display module, then install
the bezel (11) included with the upgrade kit.
21. Secure the module with the screws (12) included with the upgrade kit.
22. Align the inside end of the powder tube with the elbow then push on the
tube to seat it in the elbow.
23. Install the electrode assembly on the gun, then install the nozzle on the
electrode assembly, making sure the keys in the electrode assembly
slide into the slots on the nozzle.
24. Install the nozzle nut over the nozzle and rotate clockwise to secure.
25. Connect the 6-mm blue purge air tubing, 4-mm clear electrode air wash
tubing, and powder feed hose adapter and hose to the gun.
26. Connect the gun cable to the controller interface module.
27. Turn on the interface and check the gun functions.
Kit Parts
See Figure 11.
Item Part Description Quantity Note
− 1102653 KIT, upgrade, handgun, Encore 1
7 1088502
S GASKET, multiplier cover, handgun
1
8 1102624
S COVER, bulkhead, multiplier, handgun
1
11 1102648
S BEZEL, shield, plated
1
11A 345071
S SCREW, pan head, recessed, M3 x 35, BZN
2
27 1102621
S HANDLE, ground pad, handgun, Encore
1
27A 983520
S WASHER, lock, internal, M3, zinc
1
27B 982427
S MACHINE SCREW, pan head, recessed,
M3 x 6, zinc
1
28 1102625
S CABLE ASSEMBLY, handgun, 6 meter
1
