INSTALLATION PROCEDURES CONT...
HOPPER VERSION ONLY
Connect the vent hose to the hopper using the
provided hose clamp.
Tool Required: screwdriver
Connect the ground cable attached to the pump control unit ground stud to
a true earth ground.
Connect the main air and input power to begin
operation.
Green/Yellow = Ground/Earthing
Brown = L1/Hot
Blue = L2/Neutral
To Next Page
