Hot melt application head EP 30
19
P/N 397191B
E 2005 Nordson Corporation
EP 30
Technical Data
Electrical Data
Operating voltage 230 V
DC
Operating voltage frequency 50/60 Hz
Power consumption Refer to ID plate
Degree of protection IP 30
Voltage for solenoid valve 24 V
DC
Type of heating Electrical resistance heating elements
Possible temperature sensors FeKo thermal
element
Ni 120
Pressure Data
Control air pressure 5 to 6 bar 0.5 to 0.6 MPa 72.5 to 87 psi
Max. adhesive pressure at inlet 100 bar 10 MPa 1450 psi
Max. control module locking pressure
(without compressed air)
70 bar 7 MPa 1015 psi
Temperatures
Max. ambient temperature 60
°C
140
°F
Max. operating temperature 250
°C
482
°F
Duration of heatup Approx. 20 min
Dimensions and Weights
Dimensions Refer to technical drawing
Weight See consignment note
