Nordson FP-200 Instruction Sheet

Converting an FP-200 Extrusion Gun to an FP-200 Swirl Gun
8
Part 237494_02
E 2012 Nordson Corporation
Assembling the Extrusion Gun (contd)
5. Connect the universal elbow that was removed in step 4 of
Disassembling the Extrusion Gun to the air regulator.
3
6
7
1
5552
5
8
4
4
4
4
Figure 3 Installing the Air Regulator (Top View)
1. Mounting bracket
2. Air regulator, washers, and locking
nuts
3. T manifold inlet
4. Sealant
5. T manifold
6. Outlet air line swivel fitting
7. Extrusion air line universal elbow
8. Swirl air line universal elbow
