Nordyne JS5BD SERIES User Manual

13
Table 11. Charging Table for JS5BD-060 Series (5 Ton Units)
Suct.
Press.
OUTDOOR TEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press.
Dis.
Temp.
Liq.
Press.
Dis.
Temp.
Liq.
Press.
Dis.
Temp.
Liq.
Press.
Dis.
Temp.
Liq.
Press.
Dis.
Temp.
Liq.
Press.
Dis.
Temp.
Liq.
Press.
Dis.
Temp.
Liq.
Press.
Dis.
Temp.
68 149 141
70 151 146 166 146
72 154 151 168 151 183 151
74 154 160 171 156 185 156 200 156
76 158 163 172 163 187 161 202 160 217 160
78 175 166 189 166 204 165 219 165 234 165
80 193 169 207 170 221 169 236 169 251 169
82 210 173 224 173 238 173 253 173 267 173
84 213 177 227 177 241 177 255 177 269 177
86 231 181 245 181 259 181 271 180
88 248 185 262 186 276 185
90 265 190 279 190
92 283 194
94
TXV COOLING CHARGING CHARTS
140
160
180
200
220
240
260
280
300
320
340
360
380
400
75 80 85 90 95 100 105 110 115 120 125 130 135
Liquid Temperature (F)
Liquid Pressure (psig)
Add refrigerant when below curve
JS5BD-018 SERIES CHARGING CHART
Remove refrigerant when above curve
Figure 5. Charging Chart for 1.5 Ton Units
