Nortech PD27 Series - Page 27

307UM0200_01 May 2016 PD27x User Manual Page 27 of 30
___________ (Relay 2 Seng Presence or Pulse)
___________ (Relay 2 Polarity seng)
What applicaon is this unit used in (short descripon)_______________________________________
__________________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
POWER SUPPLY DETAILS:
Nominal Voltage: _______ V Minimum Voltage: _______ V Maximum Voltage: ________ V
AC or DC ? ______________ If AC then the Frequency _______ Hz
LOOP DETAILS
Channel 1 Channel 2
Size of loop: ____ m by ____ m Size of loop: ____ m by ____ m
Shape of loop: _____________________ Shape of loop: _____________________
Number of Turns: _____ Number of Turns: _____
Size of wire used (mm
2
or AWG) _____________ Size of wire used (mm
2
or AWG) _____________
Type of wire insulaon _____________________ Type of wire insulaon _____________________
Thickness of insulation:_____________ mm Thickness of insulaon:____________ mm
How far below the surface is the loop: ________ mm How far below the surface is the loop: _______ mm
Are there any metal objects below the loop such as concrete reinforcing, water pipes etc if yes please give details:
____________________________________________________________________________________________
____________________________________________________________________________________________
____________________________________________________________________________________________
