Are there any power cables below these loops (Yes/No) ____ If yes please give details:
_____________________________________________________________________________
_____________________________________________________________________________
_____________________________________________________________________________
Are there any other loops in the area (Yes/No) ____ If so how many? ________ and
how close to these loops are they? ________ m
FEEDER CABLE DETAILS
Channel 1 Channel 2
Length of feeder cable ________ m Length of feeder cable ________ m
Size of wire used (mm
2
or AWG) _____________ Size of wire used (mm
2
or AWG) _____________
(should be 1.5 mm
2
or larger)
Type of wire insulaon _____________________ Type of wire insulaon _____________________
Thickness of insulation:_____________ mm Thickness of insulation:____________ mm
Type of feeder cable used (screened, armoured, multicore, etc.)
____________________________________________________________________________________
____________________________________________________________________________________
In the feeder cable how many twists per meter are there?____________ (should be more than 20 per metre)
Are there any other cables close to these feeder cables? (Yes/No) _____ If yes please give details:
_____________________________________________________________________________________
FEEDER CABLE and LOOP DETAILS
Channel 1 Channel 2
Is the loop and feeder cable one connuous Is the loop and feeder cable one connuous
piece of wire or is there a joint between the piece of wire or is there a joint between the
loops and the feeder? (Yes/No) _______ loops and the feeder? (Yes/No) _______
Please give details:______________________________________________________________________
_____________________________________________________________________________________
To Next Page
